OMC intermediate housing parts drawing

OMC sterndrive intermediate housing drawing
outdrive years 1972-1986

Intermediate Housing

Intermediate Housing

982706 Electric tilt motor
982706 Electric tilt motor

P/N 018-67550 Prestolite tilt motor 1978 to 1986 OEM 982706 $195.95

Prestolite

Prestolite

P/N 018-67540 Prestolite tilt motor 1967 to 1977 OEM 26-6664 $195.95

87660 Tilt housing Kit

87660 Tilt housing Kit

P/N 87660 tilt housing seal kit before 1980 $24.95

87670

87670

P/N 87670 Tilt housing kit 1981 and up $22.95

34810 gasket set 1978-1986

34810 gasket set 1978-1986

P/N 34810 Gasket kit 1978-1986 Mechanical shift $9.95

34820 electric shift 1964-1977

34820 electric shift 1964-1977

P/N 34820 Gasket kit 1967-1977 Electric shift $9.95

22050 ball gear kit omc parts

22050 ball gear kit OMC parts

87652 electric shift seal kit

87652 electric shift seal kit

P/N 87652 Gearcase seal kit 100 to 245 hp. for years 1973 / 1977 OEM 981801 $65.95

87653

87653

P/N 87653 Gearcase seal kit year 1978 to 1986 OEM 982948 $75.95

33950

33950

Item 4

P/N 33950
Tilt motor gasket (2 units) OEM 909902 $4.95

 33060 gasket

33060 gasket

Item 7

P/N 33060 Gasket OEM 308799 $6.95

86010

86010

Item 9

P/N 86010 Oil seal (2 seals required) OEM 981195 $19.95 each

81440 o ring

Item 10

P/N 81440 O ring OEM 908383 (5 units) $6.95

85010 oil seals

85010 oil seals

Item 11

P/N 85010 Oil seal (2 seals required) OEM 313992 $7.95 each

22030 Plug

Item 12

P/N 22030 Cover included in kit P/N 22050 OEM 908062 $4.95

22330 Ball gear nut

Item 13
P/N 22330 Nut included in kit P/N 22050 OEM 908064 $4.95



Item 14

This is a New OMC Stringer Intermediate Drive Shaft The OEM part number is 909044 or 9090440

Drive shaft has 20 splines on the engine or hub side and 23 on the ball gear end.
Shaft is 13 1/4 inches long and will require a nut to hold ball gear on.

Years 1976 to 1977
Hp. 120, 140, 165, 175, 190, 225 and 235

Years 1981-1985
4 cylinder, V-6 and V-8 engines

$179.95

Plug out press on

Plug out press on

Item 14A

Press on ball gear 1968 to 1972 $329.29

22010

22010

Item 14B

P/N 22010 Ball gear included in kit P/N 22050 OEM 908063 $142.95

86700 Transom plate seal

Item 18

P/N 86700 Plate seal 1970 to 1977 (16 holes) OEM 313080 $111.95

86710

86710

Item 18

P/N 86710 Plate seal 1978 to 1986 (22 holes) OEM 313080 $119.95

22327 Bolt

22327 Bolt

Item 22

P/N 22327 Screw OEM 909386 $4.09

22420 Screw set

22420 Screw set

Item 23

P/N 22420 Screw OEM 307551 $4.95

22040 tilt shaft

Item 25

P/N 22040 Tilt shaft OEM 980183 $17.95

21512 Bearings

21512 Bearings

Item 27

P/N 21512 Bearing *Note 2 bearings (21512) are required for intermediate housing OEM 3854250 $47.95 each
