Johnson/Evinrude outboard parts drawings *How to videos

Johnson parts for water pump replacement

85 hp. 25 inch shaft year 1977 85 hp. years 1978 100 hp. years 1979 and 1980 115 hp. 25 inch shaft year 1977 115 hp. year 1978 140 hp. years 1977 to 1978 150 hp. year 1978 175 hp. years 1977 and 1978 200 hp. years 1976, 1977 and 1978 235 hp. year 1978 Johnson outboard tech drawings you can search by part number or description click here

89595 Stainless steel half moon key	P/N 89595 Water pump impeller key half moon stainless steel OEM 308928 Click on photo for impeller key
81160 O ring	P/N 81160 O ring OEM 310585 $4.95
33730 Gasket	P/N 33730 Gasket OEM 338484 $9.95
12570 Cover	P/N 12570 Cover OEM 338893 $4.95
22360 Screw kit stainless steel	P/N 22360 Screw (1 unit) OEM 302325 $4.95
86480 Cover grommet	P/N 86480 Cover grommet OEM 320943 $4.95
12430 housing with spray hole	P/N 12430 Pump housing with built in spray hole OEM 435990 $16.95
82120 O ring	P/N 82120 O ring OEM 302035 $4.95
12811 Pump cup stainless steel	P/N 12811 Pump cup OEM 338586 $10.95
86490 Water tube grommet	P/N 86490 Water tube grommet OEM 314008 $4.95
86660 Seal	P/N 86660 Seal OEM 331353 $6.95
12580 Wear plate stainless steel	P/N 12580 Wear plate OEM 338485 $8.95
22370 Screw kit stainless steel	P/N 22370 Screw 1 unit OEM 306643 $4.95
86500 Shift rod	P/N 86500 Shift rod seal OEM 321008 $4.95
81250 O ring	P/N 81250 O ring OEM 331188 $4.95
89680 Johnson water pump impeller	P/N 89680 Water pump impeller, GLM Marine aftermarket Johnson part OEM 777212 $35.95
