Comprehensive selection of used OMC parts for 400 800 Stringer OMC stern drive units

  • In the weeks to come over 200 items (used OMC parts) and tools will be posted on this web site
  • Bearing housing, pinion gear shimming unit, drive gear shimming unit, drive shaft adapter, pinion nut adapter kit, bearing carrier wrench, bearing installation tool, drive shaft bearing retainer wrench and bearing carrier puller electric shift parts, outdrive parts and lots more.
  • Specifications for your omc stern drive boat should be noted before contacting us, items like serial number, year, hp, gear ratio ect.
  • Need used OMC marine parts or OMC outdrive items not listed on our web site contact us for hard to find used OMC parts

Electric shift lower gear case
Note 8 bolt swivel housing electric shift 1964 thru 1970 # 22-551

#22-551   $1195.89

Electric shift lower unit



new old stock item
U Drive gear shaft press on.jpg
OMC ball gear shaft press on type

#22-430 $84.89



used hub.jpg
Used hub

# 22-430 Used hub $164.89



Gear case 1978 thru 1981 use with 4 cyl.

Note small piece off lower fin $360.89

For OMC servo-hydraulic units



OMC stern drive parts
U Shifter 1982 thru 1982.jpg
1982 thru 1986 Shifter used parts #22-509

#22-509 $149.89



new old stock item never used
OMC new item never used

$95.89

OEM# 982494-6M

800 series lower gear case ( used 1978 thru 1981 only ) # 22-532

#22-532 $295.89

For servo-hydraulic units 6 and 8 cylinder



U Electric shift 1971 to 1977.jpg
#22-404 Note 10 bolt swivel housing electric shift 1971 thru 1977

$1195.89 (plus core deposit)



Ball gear needs ball gear nut to hold it on

#22-141 Ball gear needs used ball gear nut to hold it on $34.89



U Press on ball gear.jpg
Ball gear press on type 1967 thru 1972

#22-142 Used press on ball gear 1967 thru 1972 $140.89



U electric shift top 1971 thru 1977.jpg
Electric shift top 1971 thru 1977

Electric shift top (used) $71.89



OMC parts for 400-800 series top cover 1978 thru 1985

Top cover 1978 thru 1985 (used) $71.89



V6 or V8 lower units 1978 trru 1981
U shifter 800 series.jpg
Shifter rod and hydrolic unit 800 series

Shifter rod and hydrolic unit 800 series $265.89



1978 thru 1981 400 series only
U 400 series OEM 909946 shifter 1978-81.jpg
400 series OEM 909946 shifter 1978 thru 1981

Shifter rod 400 series 1978 thru 1981 $195.89



U swivel housing retainer water pump.jpg
# 22-515 1971 thru 1985 Water pump adapter

# 22-515 1971 thru 1985 water pump adapter $89.89



High profile bearing housing
U OEM 313159 high profile.jpg
High profile bearing housing (used)

$209.89

OEM # 313159

U Stringer 21-20 gear set.jpg
OMC Stringer 21-20 used gear set

OMC Stringer 21-20 used gear set $234.89
Sold out


Use with right hand worm gear assembly
used steering gear.jpg
Steering gear for use with OMC outdrive tru-coarse steering

Steering gear $26.89


No true coarse steering parts in OMC sterndrive
21-16 New gears 2.jpg
21/16 upper Gear Case # 22434 Used with New Gears

#27100R (21/16 ratio)$1395.89 *after trade in*



New 21/17 gears, bearings, seals and ball gear
21-17 Used Gear Case 1.jpg
#22-403 Used OMC Upper Gear Case 21/17 R

#27200R Used OMC upper gear case 21/17 ( with trade in) $1395.89



New old stock item 1965 to 1969 or so
Older gear shaft ball gear 22 splines

Older gear shaft ball gear 22 splines $179.89



have only 1 unit ( 2 pictures )
older-gear-shaft-22-ball-gear-splines
U OMC exhaust housing 1978 to 85.jpg
# 22-666 Exhaust housing 1978 thru 1985

#22-666 $137.89



Use with electric shift omc outdrives only
U Exhaust housing 1971-77 low profile.jpg
Exhaust housing low profile 1971 thru 1977 # 22-511

#22-511 $139.89
